Switch disconnector iSW, 3P, 32A, 415V. Series: Acti 9 - Short name of the device: iSW - Switch application: Switching (opening and closing of circuits under load), disconnecting of circuits.
| Property | Value |
| Number of poles: | 3.0 |
| Rated current: | 32.0 A< /td> |
| Rated voltage: | 415.0 V |
| TE: | 2.0 |
| Switching function: | Off switch |
| With signal lamp: | no |
| Voltage type: | AC |
| Colour of the cap: | white |
| Protection class (IP): | IP20 |
| Min. Rated voltage: | 415.0 V |
| Installation depth: | 75.5 mm |
| Normally open: | 3.0 |
| Open: | 0.0 |
| Changeover: | 0.0 |
| Print/marking: | other |
| Forced separation after DIN VDE 0113: | yes |
Features
Color of the cap
White
Min. rated voltage
415.0 V
HAB
A9S60332 ISW 3-pole 32A
Manufacturer
HAN
A9S60332
GTIN
3606480088735
Printing/marking
Other
Rated voltage
415.0V
Rated current
32.0A
Installation depth
75.5 mm
With signal lamp
No
Number of poles
3.0
Switching function
Off switch
IP protection)
IP20
Voltage type
AC
TE
2.0
