Standard contactors 0.06 -75 kW In addition to an attractive and functional design, the TeSys D contactors offer quick and easy installation with a narrow width of 45 or 55 mm. They meet international standards. The power sizes 40 to 65 A are equipped with EverLink terminals. These are patented and ensure a reliable and permanent connection.
| Property | Value |
| Connection type main circuit: | Screw connection |
| Type of voltage for actuation: | AC |
| Function: | Changeover contactor |
| Rated control supply voltage AC 50 Hz: | 230.0 V |
| Rated control supply voltage AC 60 Hz: | 230.0 V |
| Degree of protection (IP): | IP20 |
| Rated operating current Ie at AC-3, 400 V: | 115.0 A |
| Protection class (NEMA): | other |
| Rated operating current Ie at AC-1, 400 V: | 200.0 A |
| Number of normally closed contacts as main contacts: | 0.0 |
| Number of normally open contacts as main contacts: | 4.0 |
| Design of electrical connection for auxiliary and control circuit: | Screw connection |
| Rail mounting possible: | no |
Features
Design of electrical connection for auxiliary and control circuit
Screw connection
Rated control supply voltage AC 50 Hz
230.0 V
HAB
LC2D115004P7 4-pole 115A 230V 50/60HZ
Manufacturer
HAN
LC2D115004P7
GTIN
3389110894929
Connection type main circuit
Screw connection
Number of normally open contacts as main contacts
4.0
Rated operational current Ie at AC-1, 400 V
200.0A
Rated operational current Ie at AC-3, 400 V
115.0A
Function
Changeover contactor
IP protection)
IP20
Protection class (NEMA)
Other
Voltage type for actuation
AC
Mounting rail possible
No
