Undervoltage release MNx Multi 9 OEM. Operating voltage (Ue) 400V AC. The associated device is triggered by opening the control circuit. A drop in the supply voltage does not trigger the associated device. A locking push-button control allows the protected circuit to be put into a safety state. With mechanical status indicator light (red) on the front. Fail-safe emergency stop function. Insensitive to changes in the control circuit voltage for improved operational continuity. The undervoltage release MNx complies with the following standards - IEC/EN 60947-1.
| Property | Value |
| Rated voltage: | 400.0 V |
| Number of fault signal switches: | 0.0 |
| Width in modular spacing: | 1.0 |
| Device mounting: | Circuit breaker |
| Suitable for max. number of poles of the main contact unit (total): | 4.0 |
| Suitable for max. current of the Main contact unit: | 63.0 A |
| With autotest for residual current function: | no |
| Number of contacts as normally open: | 0.0 |
| Number of contacts as normally closed: | 0.0 |
| Number of contacts as changeover: | 0.0 |
Features
HAB
M9 MNX-400V AC
Manufacturer
HAN
M9A26971
GTIN
3606480639159
Number of contacts as normally open
0.0
Number of contacts as changeover
0.0
Number of contacts as opener
0.0
Rated voltage
400.0V
Width in pitch units
1.0
