XCSM safety position switch, metal encapsulated, metal roller plunger, 2 break contacts and 1 make contact, 1m cable
| Property | Value |
| Number of contacts as break contacts: | 2.0 |
| Number of contacts as make contacts: | 1.0 |
| Number of contacts as changeover contacts: | 0.0 |
| Number of safety-related auxiliary contacts: | 0.0 |
| Interface design: | without |
| Design the interface for safety-related communication: | without |
| Design of the electrical connection: | with pre-assembled cable |
| Design of the switching element: | other |
| Rated operating current Ie at AC-15, 230 V: | 1.5 A |
| Rated operating current Ie at DC-13, 230 V: | 0.1 A |
| Rated control supply voltage for solenoid drive AC 50 Hz: | 240.0 V |
| Rated control supply voltage for solenoid drive AC 60 Hz: | 240.0 V |
| Rated control supply voltage magnetic drive DC: | 250.0 V |
| Width of the sensor: | 30.0 mm |
| Explosion protection category for gas: | without |
| Explosion protection category for dust: | other |
| Suitable for safety functions: | yes |
| Housing design: | other |
| Height of the sensor: | 70.0 mm |
| Sensor length: | 16.0 mm |
| With escape release: | no |
| With status display: | no |
| Protection class (IP): | IP68 |
| Ambient temperature during operation: | -25.0 to 70.0 °C |
| Housing material: | Metal |
| Closing force: | 7.0 N |
| Type of Guard locking: | Closed-circuit principle |
| With auxiliary release: | no |
| Housing coating: | other |
Features
Rated operating current Ie at DC-13, 230 V
0.1 A
HAB
XCSM3902L1 OEOES Jump Roll 1m
Manufacturer
HAN
XCSM3902L1
GTIN
3389110243765
Number of contacts as normally open
1.0
Number of contacts as changeover
0.0
Number of contacts as opener
2.0
Number of safety-related auxiliary contacts
0.0
Implementation of the interface
Without
Design of the interface for safety-related communication
Without
Design of the electrical connection
Pre-assembled with cable
Rated operating current Ie at AC-15, 230 V
1.5A
Housing coating
Other
Width of the sensor
30.0 mm
Explosion protection category for gas
Without
Explosion protection category for dust
Other
Suitable for security functions
Yes
Housing design
Other
Height of the sensor
70.0 mm
Length of the sensor
16.0 mm
With status display
No
IP protection)
IP68
Ambient temperature during operation
-25.0 to 70.0 °C
Housing material
Metal
