Miniature circuit breaker measuring function, communication AC 230V 6kA, 1+N pole, C, 16A Please note the radio approval! Country list: see validated miniature circuit breaker SENTRON 5SL6 COM for safe short-circuit and overload protection for standard applications in residential and commercial buildings. Multifunctional miniature circuit breaker with integrated measuring function and wireless communication in standard size. Tool-free assembly and disassembly of the device. Simple wiring of the feed through the rear busbar.The communication-capable 5SL6 COM miniature circuit breakers are available as a 1+N variant with various characteristics.The extensive accessories, such as remote drive, enable the functions to be expanded in many ways.Simply safe with the protective devices from SENTRON.
| Property | Value |
| Rated current: | 16 A |
| Rated voltage: | 230 V |
| Type of voltage: | AC |
| Width in modular spacing: | 1 |
| Number of poles (total): | 2 |
| Energy limitation class: | 3 |
| Additional equipment possible: | yes |
| Overvoltage category: | 3 |
| Installation depth: | 70 mm |
| Rated switching capacity Icn according to EN 60898 at 230 V: | 6 kA |
| Rated switching capacity Icn according to EN 60898 at 400 V: | 6 kA |
| Pollution degree: | 2 |
| Switching neutral conductor: | yes |
| Rated insulation voltage Ui: | 250 V |
| Rated impulse withstand voltage Uimp: | 4 kV |
| Ambient temperature during operation: | -25 to 60 °C |
| Connectable conductor cross-section, stranded: | 0.75 to 16 mm² |
| Connectable conductor cross-section, single-wire: | 0.75 to 16 mm² |
