Description
Busbar housing - industrial quality -, 5-pole, 250 A, with CU rails, L1...L3: 12 x 10 mm, N: 12 x 10 mm, PE: 12 x 10 mm, without terminals, for individual assembly, 4 x housing connectors (GGV), protection class IP65, impact resistance IK08, protection class II, rated insulation voltage Ui 690VAC/DC, halogen-free, 640 x 320 x 179, with transparent cover
| Property | Value |
| Height: | 320 mm |
| Width: | 640 mm |
| Depth: | 179 mm |
| Number of poles: | 5 |
| Rated current of rail system: | 250 A |
| Protection class (IP): | IP65 |
| Equipped with busbar: | yes |
| Mounting option: | yes |
| With transparent cover: | yes |
| Housing material: | Plastic |
| Mounting type: | Surface-mounted |
| Protection class (NEMA): | 3R |
Features
HAB
GSi453
Manufacturer
HAN
04045301
GTIN
4013902051403
Cultivation option
Yes
Width
640 mm
Height
320 mm
Mounting type
Surface-mounted
Number of poles
5
IP protection)
IP65
Protection class (NEMA)
3R
Depth
179 mm
Housing material
Plastic
