Description
Load-break switch housing - industrial quality - with external operation, lockable, 1 x load-break switch 100A, 3-pole switching, cage terminal 10 - 70 mm, for CU conductors, PE/N terminal 35 mm, 3 x housing connectors (GGV), protection class IP65, impact resistance IK08, protection class II, rated insulation voltage Ui 690VAC/DC, halogen-free, 320 x 320 x 179, with transparent cover
| Property | Value |
| Housing height: | 320 mm |
| Rated operating current Ie: | 100 A |
| Size of the Fuse links: | other |
| Rated insulation voltage Ui: | 690 V |
| Protection class (IP): | IP65 |
| Number of poles: | 3 |
| With fuse monitoring: | no |
| Max. rated operating voltage Ue at AC: | 690 V |
| Protection class (NEMA): | 3R |
Features
Rated operating current Ie
100 A
HAB
GTE210
Manufacturer
HAN
03221001
GTIN
4013902051595
Rated insulation voltage Ui
690V
Max. rated operating voltage Ue at AC
690V
With fuse monitoring
No
Number of poles
3
IP protection)
IP65
Protection class (NEMA)
3R
