LED street light series, comprising: Die-cast aluminium body painted with polymer powder paint in grainy grey after chemical surface treatment , Die-cast aluminium pole fixing part, grainy grey painted, suitable for 60 mm or 76 mm poles , Diffuser with integrated optics in transparent technopolymer, protected against UV rays and heat , Optics made of technopolymer lenses with increased light transmission , Optics for wide roads , Gasket made of resistant silicone with increased resilience , Terminal block ensures automatic power supply interruption when the light body is opened , External power connection via waterproof QUICK male-female connection including cable , Power connection via quick connector socket-plug external IP66, which allows connection to the mains without opening the light body, made of PA66 with silver-plated brass contacts, for cables 9 - 12 mm , High-performance electronic ballast , Light source consisting of several LED modules , Complies with UNI standard 10819 and regional laws regarding light pollution , Stainless steel external screws , 'SECURE LIGHT DISTRIBUTION' system that guarantees uniform light distribution even in the event of a defect in one of the LEDs , Replaceable LED module
Feature | Value |
Mounting type: | Approach |
Light source: | LED not replaceable |
With light source: | Yes |
Socket: | Other |
Circuit: | Other |
Body material: | Aluminum |
Housing color: | anthracite |
Coated: | Yes |
Cover material: | Transparent glass |
Suitable for number of bulbs: | 1 |
Max. Lamp power: | 244 W |
Voltage type: | AC |
Nominal voltage: | 220 - 240 V |
Nominal current: | 1050 - 1050 mA |
Operating device: | LED operating device, current-controlled |
With operating device: | Yes |
Type of dimming: | not dimmable |
Protection class (IP): | IP66 |
Adjustable optics: | No |
Suitable for spigot size: | 60 - 76 mm |
Impact resistance: | IK08 |
Protection class: | II |
Remote control: | without |
With radio control: | No |
Constant luminous flux control: | No |
With program-controlled light control: | No |
With connection cable: | No |
Effective luminous flux: | 23904 lm |
Light color: | white |
Color temperature: | 4000 - 4000 K |
Color rendering index CRI: | 70-79 |
