Width: 640mm, Weight: 26.5kg, Height: 630mm, With thermal insulation: yes, Depth: 230mm, Module with intermediate heat exchanger for using groundwater as a heat source. The groundwater station can be connected to all brine, water heat pumps with the exception of the large modules. The groundwater station consists of a stainless steel plate heat exchanger with 34 plates (GWS 1) or 60 plates (GWS 2), two 3-way changeover valves as shut-off valves with filling and draining taps and a double-shell housing made of heat-insulating plastic.
| Property | Value |
| Max. Working pressure: | 3 bar |
| Secondary temperature: | 7 to 20 °C |
| Height: | 630 mm |
| Width: | 640 mm |
| Depth: | 230 mm |
| Primary nominal inner diameter: | 1 1/4 inch (32) |
| Primary pipe outer diameter: | 28 mm |
| Secondary nominal inner diameter: | 1 1/4 inch (32) |
| Secondary pipe outer diameter: | 28 mm |
