LNC performance characteristics: Digital/Universal Twin LNC Number of LNC outputs: 2 LNC for two/multi-user system: yes Number of max. users: 2 Min. reception frequency range (GHz): 10.7 Max. reception frequency range (GHz): 12.75 Output frequency lower limit (MHz): 950 Output frequency upper limit (MHz): 2150 Noise figure (typ.) high band (dB): 0.7 Noise figure (typ.), low band (dB): 0.7 Antenna gain (dBi): 32.2 Antenna gain determined at x (GHz): 11.3 1st oscillator frequency (GHz): 9.75 2nd oscillator frequency (GHz): 10.6 22 KHz switching frequency: yes Current consumption (A): 0.19Reflector Reflector width (cm): 75 Reflector height (cm): 75 Reflector material: Reflector made of aluminum, coated Offset angle (degrees): 30Antenna positioner min. voltage for motor drive (V): 11.5 max. voltage for motor drive (V): 19Mechanics/Mounting Wall mounting: yes LNC mounting dimension, diameter (mm): 40 Weight (kg): 2.9 Wall mounting as accessory: yes
