Time range 0.5-20 min. continuously adjustable, button input with max. 150 mA glow lamp load and electronic overload protection, additional control input galvanically isolated for DC 8...110 V and AC 8...230 V e.g. combination with door intercom systems, connection for 3- or 4-wire can be switched on later. Manual switch for permanent light.
| Property | Value |
| Width in pitch units: | 1 |
| Off delay: | 0.5 to 20 min |
| Function: | electronic |
| Mounting type: | DIN rail |
| Control voltage 1: | 220 to 240 V |
| Rated switching current: | 16 A |
| Control voltage type 1: | AC |
| Current surge function selectable: | no |
| Control voltage 2: | 8 to 240 V |
| Control voltage type 2: | AC/DC |
| Frequency of control voltage 1: | 50 to 60 Hz |
| Frequency of control voltage 2: | 0 to 60 Hz |
| Circuit type: | 3- and 4-wire circuit |
| Switch-off warning: | without |
| Follow-up switching: | can be switched on again |
| Type of supply voltage: | AC |
| Installation depth: | 60 mm |
| Max. switching current (cos phi = 0.6): | 10 A |
| Button glow lamp current: | 150 mA |
| Supply voltage: | 220 to 240 V |
| Max. incandescent lamp load: | 2300 W |
| Max. fluorescent lamp load: | 2300 VA |
| Max. fluorescent lamp load (duo circuit): | 2300 VA |
| Max. fluorescent lamp load (parallel compensated): | 400 VA |
| Number of contacts as normally open: | 1 |
Features
Type of voltage of the supply voltage
AC
Supply voltage
220 to 240 V
Circuit type
3- and 4-wire circuit
Max. fluorescent lamp load
2300 VA
Manufacturer
HAN
0030002
GTIN
4003468010501
Number of contacts as normally open
1
Width in pitch units
1
Installation depth
60 mm
Function
Electronic
Mounting type
DIN rail
Supply voltage
220 to 240 V
