KNX 1-way heating actuator flush-mounted, Silent control of thermal actuators 230 V AC, Secure commissioning and communication through support of KNX Data Secure, Function selection as heating actuator (constant or switching control value) or as heating controller (integrated temperature controller heating/cooling), Integrated valve protection function and summer operation, Easy installation thanks to particularly compact housing, 2 binary inputs for potential-free contacts such as buttons, switches, window contacts, temperature sensor (input I2), Integrated temperature monitoring for increased operational reliability e.g. in the event of overload
| Property | Value |
| Number of outputs: | 1 |
| Switching voltage: | 230 V |
| KNX bus system: | yes |
| Max. Switching current (resistive load): | 1 A |
| Max. Output current: | 1 A |
| Protection class (IP): | other |
| Bus system radio bus: | no |
| Bus system LON: | no |
| Bus system Powernet: | no |
| Other bus systems: | without |
| Mounting type: | Flush-mounted |
| With bus connection: | yes |
| Control value continuous: | yes |
| Switching control value: | yes |
| Valve protection function: | yes |
| Manual control: | no |
| Bidirectional radio: | no |
| Removable bus module: | no |
| KNX radio bus system: | no |
| Min. depth of device box: | 40 mm |
Features
Number of outputs
1
HAB
HU 1 KNX
Manufacturer
HAN
4942540
GTIN
4003468491522
Other bus systems
Without
Bus system radio bus
No
KNX bus system
Yes
KNX radio bus system
No
LON bus system
No
Powernet bus system
No
Radio bidirectional
No
Min. depth of the device box
40 mm
With bus connection
Yes
Mounting type
Flush-mounted
IP protection)
Other
