2022-103/000-006 2.5qmm 3-pole 2.50qmm blue 1 conductor female connector Manufacturer article number: 2022-103/000-006, Manufacturer article name: 2.5qmm 3-pole 2.50qmm blue
| Property | Value |
| Number of poles: | 3 |
| Color: | blue |
| Rated voltage: | 690 V |
| Material of the insulating body: | Thermoplastic |
| Rated current In: | 24 A |
| Operating temperature: | 105 °C |
| Connectable conductor cross-section, single-wire: | 0.75 to 4 mm² |
| Connectable conductor cross-section, multi-wire: | 0.25 to 2.5 mm² |
| Connectable conductor cross-section, fine-wire with wire end ferrule: | 0.75 to 2.5 mm² |
| Connectable conductor cross-section, fine-wire without wire end ferrule: | 0.25 to 4 mm² |
| Mounting type: | other |
| Design of electrical connection 1: | spring-loaded connection |
| Design of electrical connection 2: | spring-loaded connection |
| Number of terminal points per pole: | 1 |
| Flammability class of the insulating material according to UL 94: | V0 |
| End plate required: | no |
| Explosion-tested version 'Ex e': | no |
| Transparent: | no |
Features
HAB
2.5qmm 3-pin 2.50qmm blue
Minimal order
100 pcs
Manufacturer
HAN
2022-103/000-006
GTIN
4045454705435
Connectable conductor cross-section solid
0.75 to 4 mm²
Connectable conductor cross-section stranded
0.25 to 2.5 mm²
Rated voltage
690V
Rated current In
24A
Operating temperatur
105°C
Flammability class of the insulating material according to UL 94
V0
Color
Mounting type
Other
Number of poles
3
Transparent
No
