THT pin header, solder pin Ø 1.0 mm, angled, pitch 3.5 mm, 3-pin, black
| Property | Value |
| Number of plug contact rows: | 1 |
| Type of banding: | without |
| Type of PCB mounting: | Connection contact |
| Design of the electrical connection: | Solder connection |
| Mounting type: | soldering |
| Rated voltage: | 160 V |
| Rated impulse voltage: | 2.5 kV |
| Rated current In: | 10 A |
| Operating temperature: | -60 to 100 °C |
| Flammability class of the insulating material according to UL94: | V0 |
| Connection pin diameter: | 1 mm |
| Housing color: | black |
| Contact design: | pin |
| Length of pin: | 3.6 mm |
| Pitch of connections: | 3.5 mm |
| Pitch of contacts: | 3.5 mm |
| Connector design: | free connector |
| Overvoltage category: | III |
| Pollution level: | 2 |
| Material of contact coating: | tin |
| Material of insulating body: | thermoplastic |
| Angle circuit board/contact: | 0°/180° (horizontal) |
| Connection type: | flexible circuit board connector |
| Number of poles: | 3 |
Features
Rated surge voltage
2.5 kV
Minimal order
400 pcs
Manufacturer
HAN
2091-1723
GTIN
4055143935463
Design of the electrical connection
Solder connection
Mounting type
Soldering
Rated voltage
160V
Rated current In
10A
Operating temperatur
-60 to 100 °C
Housing color
Black
Number of poles
3
Connection type
Flexible circuit board connector
Degree of contamination
2
Overvoltage category
III
