232-179 SPRING.STRAIGHT.SOLDERED. 5.08MM 19P.
| Property | Value |
| Number of rows of connector contacts: | < td>1|
| Type of banding: | without |
| Type of PCB mounting: | Connection contact |
| Design of the electrical connection: | Solder connection |
| Mounting type: | soldering |
| Rated voltage: | 320 V |
| Rated impulse voltage: | 4 kV |
| Rated current In: | 12 A |
| Operating temperature: | -60 to 85 °C |
| Flammability class of the insulating material according to UL94: | V0 |
| Suitable for PCB thickness: | 1.5 mm |
| Housing color: | orange |
| Contact design : | Pin |
| Length of pin: | 5 mm |
| Pitch of the connections: | 5.08 mm |
| Pitch of the contacts: | 5.08 mm |
| Connector design: | free connector |
| Overvoltage category: | III |
| Degree of contamination: | 2 |
| Material of contact coating: | Tin |
| Material of the insulating body: | Thermoplastic |
| Angle circuit board/contact: | 90° (vertical to above) |
| Connection type: | flexible PCB connector |
| Number of pins: | 19 |
Features
Rated surge voltage
4 kV
Minimal order
10 pcs
Manufacturer
HAN
232-179
GTIN
4044918578967
Design of the electrical connection
Solder connection
Mounting type
Soldering
Rated voltage
320V
Rated current In
12A
Operating temperatur
-60 to 85 °C
Housing color
Orange
Number of poles
19
Connection type
Flexible circuit board connector
Degree of contamination
2
Overvoltage category
III
