4-CONDUCTOR TERMINAL BLUE
| Property | Value |
| Number of poles: | 1 |
| Rated voltage: | 400 V |
| Insulating body material: | Thermoplastic |
| Rated current In: | 18 A |
| Color: | blue |
| Operating temperature: | -30 to 85 °C |
| QS fine-stranded: | 0.08 to 1.5 mm² |
| QS single-wire: | 0.08 to 1.5 mm² |
| QS multi-wire: | 0.08 to 1.5 mm² |
| Mounting type: | other |
| Design of electrical connection 1: | spring-loaded connection |
| Design of electrical connection 2: | spring-loaded connection |
| Number of terminals per pole: | 4 |
| Flammability class of the Insulating material according to UL94: | V0 |
| End plate required: | yes |
| Explosion-tested version Ex e: | no |
| Transparent: | no |
| Halogen-free: | yes |
| Width: | 8 mm |
| Height: | 25.1 mm |
| Depth: | 17.1 mm |
