1-conductor female connector, lever, Push-in CAGE CLAMP®, 1.5 mm², pitch 3.5 mm, 12-pin, 100% protected against mismating, 1.50 mm², light gray
| Property | Value |
| Connectable cable type: | Round cable |
| Connectable conductor cross-section, single-wire: | 0.14 to 1.5 mm² |
| Connectable conductor cross-section, fine-stranded with wire end ferrule: | 0.25 to 0.75 mm² |
| Connectable conductor cross-section, fine-stranded without Wire end ferrule: | 0.14 to 1.5 mm² |
| Connectable conductor cross-section, stranded: | 0.2 to 1.5 mm² |
| Number of plug contact rows: | 1 |
| Design of the electrical connection: | Spring-loaded connection |
| Rated voltage: | 160 V |
| Rated impulse voltage: | 2.5 kV |
| Rated current In: | 10 A |
| Operating temperature: | -60 to 100 °C |
| Flammability class of the insulating material according to UL94: | V0 |
| Housing color: | gray |
| Contact design: | socket |
| With protective conductor: | no |
| Pitch of the connections: | 3.5 mm |
| Pitch of the contacts: | 3.5 mm |
| Protection class (IP), mounted: | IP20 |
| Overvoltage category: | III |
| Pollution level: | 2 |
| Material of the contact coating: | Tin |
| Material of the housing: | Plastic |
| Material of the insulating body: | Thermoplastic |
| Material of the contact: | Other copper alloys |
| Angle of contact/conductor connection: | 180° (horizontal) |
| Connection type: | PCB to cable |
| Number of pins: | 12 |
Features
Rated surge voltage
2.5 kV
Minimal order
50 pcs
Manufacturer
HAN
2734-1112/327-000
GTIN
4066966216462
Connectable conductor cross-section solid
0.14 to 1.5 mm²
Connectable conductor cross-section stranded
0.2 to 1.5 mm²
Design of the electrical connection
Spring-loaded connection
Rated voltage
160V
Rated current In
10A
Operating temperatur
-60 to 100 °C
Housing color
Gray
Number of poles
12
Connection type
PCB to cable
Degree of contamination
2
Housing material
Plastic
Overvoltage category
III
