757-164 M12 SENSOR/ACTUATOR BOX 6F/4P/M23
| Property | Value |
| Number of sensor/actuator slots: | 6 |
| Number of channels per slot: | 6 |
| Design of the outlets for sensor/actuator cables: | M12 |
| Number of poles of the sensor/actuator slots: | 4 |
| Rated voltage: | 32 V |
| Pollution level: | 3 |
| Operating voltage: | 10 to 30 V |
| Max. current load per I/O signal: | 2 A |
| Max. Current carrying capacity per connection base: | 9 A |
| Material of the contact base: | Brass |
| Material of the contact coating: | Gold |
| Material of the insulating body: | PA |
| Threaded bushings of the sensor/actuator slots: | M12 |
| With LED display: | yes |
| With potential separation: | yes |
| Connection for NPN sensors: | no |
| Drag chain suitability of the fixed cable version: | no |
| Housing material: | plastic |
| Housing color: | gray |
| Operating temperature: | -25 to 80 °C |
| Protection class (IP): | IP67 |
| Explosion protection category for gas: | without |
| Explosion protection category for dust: | without |
| Width: | 60 mm |
| Height: | 34 mm |
| Length: | 123 mm |
Features
Operating voltage
10 to 30 V
Manufacturer
HAN
757-164
GTIN
4050821054290
Rated voltage
32V
Operating temperatur
-25 to 80 °C
Width
60 mm
Explosion protection category for gas
Without
Explosion protection category for dust
Without
Housing color
Gray
Height
34 mm
Length
123 mm
With LED display
Yes
IP protection)
IP67
Degree of contamination
3
Housing material
Plastic
