Lambda switch module, nominal input voltage AC 230 V, 1 normally open contact, limiting continuous current 16 A, status display red, 18 mm width, 2.50 mm², gray
| Property | Value |
| Number of contacts as normally open contacts: | 1 |
| Rated control supply voltage Us at AC 50 Hz: | 230 V |
| Rated control supply voltage Us at AC 60 Hz: | 230 V |
| Type of voltage for actuation: | AC |
| Design of the electrical connection: | Spring-loaded connection |
| Drive, polarity: | unpolarized |
| Height: | 90 mm |
| Width: | 17.5 mm |
| Depth: | 55 mm |
| Switching behavior of the drive: | monostable |
| Type of switching contact: | Single contact |
| With positively guided contacts: | no |
| With removable Terminals: | no |
| Complete device with base: | yes |
| Protection class (IP): | IP20 |
| Rated current: | 16 A |
| With LED display: | yes |
Features
Complete device with base
Yes
Drive, polarity
Unpolarized
Type of switching contact
Single contact
Switching behavior of the drive
Monostable
With positively guided contacts
No
HAB
789-570
Manufacturer
HAN
789-570
GTIN
4017332790222
Number of contacts as normally open
1
Design of the electrical connection
Spring-loaded connection
Rated control supply voltage Us at AC 50 Hz
230V
Rated control supply voltage Us at AC 60 Hz
230V
Width
17.5 mm
Height
90 mm
With LED display
Yes
With removable clamps
No
Rated current
16A
IP protection)
IP20
Voltage type for actuation
AC
Depth
55 mm
